Kaggle/House Prices

Detailed Data Exploration in Python by Angela (With Python)

https://www.kaggle.com/xchmiao/house-prices-advanced-regression-techniques/detailed-data-exploration-in-python/comments

##########################################################################

본 게시글은 Kaggle Competition에서 House prices의 TOP Kernel 중 하나를 번역한 것임.

저작권에는 문제가 없어 보이나 문제가 될시 바로 삭제하겠음.

##########################################################################

Overall

In [1]:

# This Python 3 environment comes with many helpful analytics libraries installed # It is defined by the kaggle/python docker image: https://github.com/kaggle/docker-python # For example, here's several helpful packages to load in import numpy as np # 선형대수linear algebra import pandas as pd # 데이터처리, CSV 파일 I/O(예를 들어 read_csv) # Input data are available in the "../input/" directory. # For example, running this (by clicking run or pressing Shift+Enter) will list the files in the input directory from subprocess import check_output print(check_output(["ls", "../input"]).decode("utf8")) # Any results you write to the current directory are saved as output.

sample_submission.csv
test.csv
train.csv

In [2]:
df = pd.read_csv('../input/train.csv')
#df.drop('SalePrice', axis = 1, inplace = True)
#test = pd.read_csv('../input/test.csv')
#df = df.append(test, ignore_index = True)
df.head()
Out[2]:
IdMSSubClassMSZoningLotFrontageLotAreaStreetAlleyLotShapeLandContourUtilities...PoolAreaPoolQCFenceMiscFeatureMiscValMoSoldYrSoldSaleTypeSaleConditionSalePrice
0160RL65.08450PaveNaNRegLvlAllPub...0NaNNaNNaN022008WDNormal208500
1220RL80.09600PaveNaNRegLvlAllPub...0NaNNaNNaN052007WDNormal181500
2360RL68.011250PaveNaNIR1LvlAllPub...0NaNNaNNaN092008WDNormal223500
3470RL60.09550PaveNaNIR1LvlAllPub...0NaNNaNNaN022006WDAbnorml140000
4560RL84.014260PaveNaNIR1LvlAllPub...0NaNNaNNaN0122008WDNormal250000

5 rows × 81 columns

In [3]:
df.describe()
/opt/conda/lib/python3.5/site-packages/numpy/lib/function_base.py:3834: RuntimeWarning: Invalid value encountered in percentile
  RuntimeWarning)
Out[3]:
IdMSSubClassLotFrontageLotAreaOverallQualOverallCondYearBuiltYearRemodAddMasVnrAreaBsmtFinSF1...WoodDeckSFOpenPorchSFEnclosedPorch3SsnPorchScreenPorchPoolAreaMiscValMoSoldYrSoldSalePrice
count1460.0000001460.0000001201.0000001460.0000001460.0000001460.0000001460.0000001460.0000001452.0000001460.000000...1460.0000001460.0000001460.0000001460.0000001460.0000001460.0000001460.0000001460.0000001460.0000001460.000000
mean730.50000056.89726070.04995810516.8280826.0993155.5753421971.2678081984.865753103.685262443.639726...94.24452146.66027421.9541103.40958915.0609592.75890443.4890416.3219182007.815753180921.195890
std421.61000942.30057124.2847529981.2649321.3829971.11279930.20290420.645407181.066207456.098091...125.33879466.25602861.11914929.31733155.75741540.177307496.1230242.7036261.32809579442.502883
min1.00000020.00000021.0000001300.0000001.0000001.0000001872.0000001950.0000000.0000000.000000...0.0000000.0000000.0000000.0000000.0000000.0000000.0000001.0000002006.00000034900.000000
25%365.75000020.000000NaN7553.5000005.0000005.0000001954.0000001967.000000NaN0.000000...0.0000000.0000000.0000000.0000000.0000000.0000000.0000005.0000002007.000000129975.000000
50%730.50000050.000000NaN9478.5000006.0000005.0000001973.0000001994.000000NaN383.500000...0.00000025.0000000.0000000.0000000.0000000.0000000.0000006.0000002008.000000163000.000000
75%1095.25000070.000000NaN11601.5000007.0000006.0000002000.0000002004.000000NaN712.250000...168.00000068.0000000.0000000.0000000.0000000.0000000.0000008.0000002009.000000214000.000000
max1460.000000190.000000313.000000215245.00000010.0000009.0000002010.0000002010.0000001600.0000005644.000000...857.000000547.000000552.000000508.000000480.000000738.00000015500.00000012.0000002010.000000755000.000000

8 rows × 38 columns

In [4]:
df.columns
Out[4]:
Index(['Id', 'MSSubClass', 'MSZoning', 'LotFrontage', 'LotArea', 'Street',
       'Alley', 'LotShape', 'LandContour', 'Utilities', 'LotConfig',
       'LandSlope', 'Neighborhood', 'Condition1', 'Condition2', 'BldgType',
       'HouseStyle', 'OverallQual', 'OverallCond', 'YearBuilt', 'YearRemodAdd',
       'RoofStyle', 'RoofMatl', 'Exterior1st', 'Exterior2nd', 'MasVnrType',
       'MasVnrArea', 'ExterQual', 'ExterCond', 'Foundation', 'BsmtQual',
       'BsmtCond', 'BsmtExposure', 'BsmtFinType1', 'BsmtFinSF1',
       'BsmtFinType2', 'BsmtFinSF2', 'BsmtUnfSF', 'TotalBsmtSF', 'Heating',
       'HeatingQC', 'CentralAir', 'Electrical', '1stFlrSF', '2ndFlrSF',
       'LowQualFinSF', 'GrLivArea', 'BsmtFullBath', 'BsmtHalfBath', 'FullBath',
       'HalfBath', 'BedroomAbvGr', 'KitchenAbvGr', 'KitchenQual',
       'TotRmsAbvGrd', 'Functional', 'Fireplaces', 'FireplaceQu', 'GarageType',
       'GarageYrBlt', 'GarageFinish', 'GarageCars', 'GarageArea', 'GarageQual',
       'GarageCond', 'PavedDrive', 'WoodDeckSF', 'OpenPorchSF',
       'EnclosedPorch', '3SsnPorch', 'ScreenPorch', 'PoolArea', 'PoolQC',
       'Fence', 'MiscFeature', 'MiscVal', 'MoSold', 'YrSold', 'SaleType',
       'SaleCondition', 'SalePrice'],
      dtype='object')
In [5]:
import seaborn as sns
import matplotlib.pyplot as plt
%matplotlib inline
In [6]:
print("Some Statistics of the Housing Price:\n")
print(df['SalePrice'].describe()) # 종속 변수 SalePrice의 기초통계량 출력.
print("\nThe median of the Housing Price is: ", df['SalePrice'].median(axis = 0))
Some Statistics of the Housing Price:

count      1460.000000
mean     180921.195890
std       79442.502883
min       34900.000000
25%      129975.000000
50%      163000.000000
75%      214000.000000
max      755000.000000
Name: SalePrice, dtype: float64

The median of the Housing Price is:  163000.0
In [7]:
sns.distplot(df['SalePrice'], kde = False, color = 'b', hist_kws={'alpha': 0.9})
Out[7]:
<matplotlib.axes._subplots.AxesSubplot at 0x7f74cdf82358>

Numerical Features

In [8]:

# Id 를 제외한 수치형변수들간 상관계수

corr = df.select_dtypes(include = ['float64', 'int64']).iloc[:, 1:].corr()

plt.figure(figsize=(12, 12)) sns.heatmap(corr, vmax=1, square=True)

Out[8]:
<matplotlib.axes._subplots.AxesSubplot at 0x7f74ce002a58>
In [9]:
cor_dict = corr['SalePrice'].to_dict()
del cor_dict['SalePrice']

# SalePrice와의 상관계수를 내림차순으로 정렬. print("List the numerical features decendingly by their correlation with Sale Price:\n") for ele in sorted(cor_dict.items(), key = lambda x: -abs(x[1])): print("{0}: \t{1}".format(*ele))

List the numerical features decendingly by their correlation with Sale Price:

OverallQual: 	0.7909816005838047
GrLivArea: 	0.7086244776126511
GarageCars: 	0.640409197258349
GarageArea: 	0.6234314389183598
TotalBsmtSF: 	0.6135805515591944
1stFlrSF: 	0.6058521846919166
FullBath: 	0.5606637627484452
TotRmsAbvGrd: 	0.5337231555820238
YearBuilt: 	0.5228973328794967
YearRemodAdd: 	0.5071009671113867
GarageYrBlt: 	0.48636167748786213
MasVnrArea: 	0.4774930470957107
Fireplaces: 	0.4669288367515242
BsmtFinSF1: 	0.38641980624215627
LotFrontage: 	0.35179909657067854
WoodDeckSF: 	0.32441344456813076
2ndFlrSF: 	0.31933380283206614
OpenPorchSF: 	0.31585622711605577
HalfBath: 	0.2841076755947784
LotArea: 	0.2638433538714063
BsmtFullBath: 	0.22712223313149718
BsmtUnfSF: 	0.214479105546969
BedroomAbvGr: 	0.1682131543007415
KitchenAbvGr: 	-0.1359073708421417
EnclosedPorch: 	-0.12857795792595636
ScreenPorch: 	0.11144657114291048
PoolArea: 	0.09240354949187278
MSSubClass: 	-0.08428413512659523
OverallCond: 	-0.0778558940486776
MoSold: 	0.04643224522381936
3SsnPorch: 	0.04458366533574792
YrSold: 	-0.028922585168730426
LowQualFinSF: 	-0.02560613000068015
MiscVal: 	-0.02118957964030379
BsmtHalfBath: 	-0.016844154297359294
BsmtFinSF2: 	-0.011378121450215216

집값(Sales price)은 OverallQual, GrLivArea(GarageCars), GargeArea, TotalBsmtSF, 1stFlrSF, FullBath, TotRmsAbvGrd, YearBuilt, YearRemodAdd, GargeYrBlt, MasVnrArea and Fireplaces 들과 강한 상관관계를 지닌다. 그러나 이 변수들 간에도 상당히 높은 상관관계, 즉 다중공선성을 띈다.

In [10]:

# SalePrice에 대한 OverallQuall의 회귀선

sns.regplot(x = 'OverallQual', y = 'SalePrice', data = df, color = 'Orange')

Out[10]:
<matplotlib.axes._subplots.AxesSubplot at 0x7f74cb061ba8>
In [11]:

# 높은 상관관계를 지닌 변수들의 SalePrice에 대한 산점도.

plt.figure(1)
f, axarr = plt.subplots(3, 2, figsize=(10, 9))
price = df.SalePrice.values
axarr[0, 0].scatter(df.GrLivArea.values, price)
axarr[0, 0].set_title('GrLiveArea')
axarr[0, 1].scatter(df.GarageArea.values, price)
axarr[0, 1].set_title('GarageArea')
axarr[1, 0].scatter(df.TotalBsmtSF.values, price)
axarr[1, 0].set_title('TotalBsmtSF')
axarr[1, 1].scatter(df['1stFlrSF'].values, price)
axarr[1, 1].set_title('1stFlrSF')
axarr[2, 0].scatter(df.TotRmsAbvGrd.values, price)
axarr[2, 0].set_title('TotRmsAbvGrd')
axarr[2, 1].scatter(df.MasVnrArea.values, price)
axarr[2, 1].set_title('MasVnrArea')
f.text(-0.01, 0.5, 'Sale Price', va='center', rotation='vertical', fontsize = 12)
plt.tight_layout()
plt.show()
<matplotlib.figure.Figure at 0x7f74cb06e7f0>
In [12]:
fig = plt.figure(2, figsize=(9, 7))
plt.subplot(211)
plt.scatter(df.YearBuilt.values, price)
plt.title('YearBuilt')

plt.subplot(212)
plt.scatter(df.YearRemodAdd.values, price)
plt.title('YearRemodAdd')

fig.text(-0.01, 0.5, 'Sale Price', va = 'center', rotation = 'vertical', fontsize = 12)

plt.tight_layout()

Categorical Features

In [13]:
print(df.select_dtypes(include=['object']).columns.values)
['MSZoning' 'Street' 'Alley' 'LotShape' 'LandContour' 'Utilities'
 'LotConfig' 'LandSlope' 'Neighborhood' 'Condition1' 'Condition2'
 'BldgType' 'HouseStyle' 'RoofStyle' 'RoofMatl' 'Exterior1st' 'Exterior2nd'
 'MasVnrType' 'ExterQual' 'ExterCond' 'Foundation' 'BsmtQual' 'BsmtCond'
 'BsmtExposure' 'BsmtFinType1' 'BsmtFinType2' 'Heating' 'HeatingQC'
 'CentralAir' 'Electrical' 'KitchenQual' 'Functional' 'FireplaceQu'
 'GarageType' 'GarageFinish' 'GarageQual' 'GarageCond' 'PavedDrive'
 'PoolQC' 'Fence' 'MiscFeature' 'SaleType' 'SaleCondition']
  • Neighborhood
In [14]:
plt.figure(figsize = (12, 6))
sns.boxplot(x = 'Neighborhood', y = 'SalePrice',  data = df)
xt = plt.xticks(rotation=45)
In [15]:
plt.figure(figsize = (12, 6))
sns.countplot(x = 'Neighborhood', data = df)
xt = plt.xticks(rotation=45)

차원 축소를 위해 비슷한 가격대를 가진 Neighborhood들을 그룹핑 할 수 있다.

Housing Price vs Sales

  • 판매타입과 판매될 집 상태 (Sale Type & Condition)
  • 판매계절성 (Sales Seasonality)
In [16]:
fig, ax = plt.subplots(2, 1, figsize = (10, 6))
sns.boxplot(x = 'SaleType', y = 'SalePrice', data = df, ax = ax[0])
sns.boxplot(x = 'SaleCondition', y = 'SalePrice', data = df, ax = ax[1])
plt.tight_layout()
In [17]:
g = sns.FacetGrid(df, col = 'YrSold', col_wrap = 3)
g.map(sns.boxplot, 'MoSold', 'SalePrice', palette='Set2', order = range(1, 13))\
.set(ylim = (0, 500000))
plt.tight_layout()

Sale's timing does not seem to hugely affect the house.

  • Housing Style
In [18]:
fig, ax = plt.subplots(2, 1, figsize = (10, 8))
sns.boxplot(x = 'BldgType', y = 'SalePrice', data = df, ax = ax[0])
sns.boxplot(x = 'HouseStyle', y = 'SalePrice', data = df, ax = ax[1])
Out[18]:
<matplotlib.axes._subplots.AxesSubplot at 0x7f74a92c1198>
  • Housing Condition
In [19]:
fig, ax = plt.subplots(2, 1, figsize = (10, 8))
sns.boxplot(x = 'Condition1', y = 'SalePrice', data = df, ax = ax[0])
sns.boxplot(x = 'Exterior1st', y = 'SalePrice', data = df, ax = ax[1])
x = plt.xticks(rotation = 45)
plt.show()
  • Basement Conditions
In [20]:
fig, ax = plt.subplots(2, 2, figsize = (10, 8))
sns.boxplot('BsmtCond', 'SalePrice', data = df, ax = ax[0, 0])
sns.boxplot('BsmtQual', 'SalePrice', data = df, ax = ax[0, 1])
sns.boxplot('BsmtExposure', 'SalePrice', data = df, ax = ax[1, 0])
sns.boxplot('BsmtFinType1', 'SalePrice', data = df, ax = ax[1, 1])
Out[20]:
<matplotlib.axes._subplots.AxesSubplot at 0x7f74a8ff4ef0>
  • Home Functionality
In [21]:
sns.violinplot('Functional', 'SalePrice', data = df)
Out[21]:
<matplotlib.axes._subplots.AxesSubplot at 0x7f74a908a550>
  • FirePlaceQu : 벽난로 질
In [22]:
sns.factorplot('FireplaceQu', 'SalePrice', data = df, color = 'm', \
               estimator = np.median, order = ['Ex', 'Gd', 'TA', 'Fa', 'Po'], size = 4.5,  aspect=1.35)
Out[22]:
<seaborn.axisgrid.FacetGrid at 0x7f74a8dd5fd0>
In [23]:

pd.crosstab(df.Fireplaces, df.FireplaceQu) # 벽낸로 갯수와 질 교차표.

Out[23]:
FireplaceQuExFaGdPoTA
Fireplaces
1192832420259
24454053
311201
In [24]:
g = sns.FacetGrid(df, col = 'FireplaceQu', col_wrap = 3, col_order=['Ex', 'Gd', 'TA', 'Fa', 'Po'])
g.map(sns.boxplot, 'Fireplaces', 'SalePrice', order = [1, 2, 3], palette = 'Set2')
Out[24]:
<seaborn.axisgrid.FacetGrid at 0x7f74a8f8d2e8>
  • Heating : 난방의 종류

Ames는 추운지역이다. 따라서 난방(또는 벽난로의 질)은 꽤 중요한 요소이다.

In [25]:

pd.crosstab(df.HeatingQC, df.CentralAir) # 중앙난방 유무와 난방의 질과 상태의 교차표

Out[25]:
CentralAirNY
HeatingQC
Ex8733
Fa2425
Gd13228
Po10
TA49379
In [26]:
pd.crosstab(df.HeatingQC, df.FireplaceQu) # 벽난로의 질과  난방의 질과 상태의 교차표
Out[26]:
FireplaceQuExFaGdPoTA
HeatingQC
Ex22142544160
Fa011315
Gd2345557
TA015681091
In [27]:
sns.factorplot('HeatingQC', 'SalePrice', hue = 'CentralAir', estimator = np.mean, data = df,
             size = 4.5, aspect = 1.4)
Out[27]:
<seaborn.axisgrid.FacetGrid at 0x7f74a8958cc0>

명백히, 중앙냉(난)방이 있고 없고는 가격에 큰 영향을 미친다.

In [28]:
fig, ax = plt.subplots(1, 2, figsize = (10, 4))
sns.boxplot('Electrical', 'SalePrice', data = df, ax = ax[0]).set(ylim = (0, 400000))
sns.countplot('Electrical', data = df)
plt.tight_layout()
  • Kitchen Quality
In [29]:
sns.factorplot('KitchenQual', 'SalePrice', estimator = np.mean,
               size = 4.5, aspect = 1.4, data = df, order = ['Ex', 'Gd', 'TA', 'Fa'])
Out[29]:
<seaborn.axisgrid.FacetGrid at 0x7f74a88bc710>
  • MSZonig : 토지용도 구별
In [30]:
sns.boxplot(x = 'MSZoning', y = 'SalePrice', data = df)
Out[30]:
<matplotlib.axes._subplots.AxesSubplot at 0x7f74a8752cc0>
  • Street & Alley Access  : 도로 그리고 골목길 접근성.
In [31]:
fig, ax = plt.subplots(1, 2, figsize = (10, 4))
sns.boxplot(x = 'Street', y = 'SalePrice', data = df, ax = ax[0])
sns.boxplot(x = 'Alley', y = 'SalePrice', data = df, ax = ax[1])
plt.tight_layout()
In [32]:

# Alley에서 결측값이 많다. Alley가 NA일때, Street은 'Pave'.

print("The NA's in Alley is: ", df['Alley'].isnull().sum())
print("\nThere are so many NA's in Alley. When Alley is NA, Street = ",
      df[df.Alley.notnull()].Street.unique())
print("\n", pd.crosstab(df.Street, df.Alley))
The NA's in Alley is:  1369

There are so many NA's in Alley. When Alley is NA, Street =  ['Pave']

 Alley   Grvl  Pave
Street
Pave      50    41
